Shacman SR150 Refurbished Rotary Drill Rig Second Hand Borewell Machine 18432mm

Product Categories
Hunan Jyfy Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Shacman SR150 Refurbished Rotary Drill Rig Second Hand Borewell Machine 18432mm

Brand Name : Shacman

Model Number : SR150

Certification : ISO9000, CE

Place of Origin : China

MOQ : 1 unit

Price : USD 50000~60000 per unit (FOB)

Payment Terms : L/C, T/T, D/P, D/A, Western Union

Supply Ability : 5 units per month

Delivery Time : 15 work days

Packaging Details : Export standard

Condition : Refurbished

Year of Manufacture : 2013

Aftersales service : Provided

Warranty : Provided

Maximum borehole diameter : 1500mm

Maximum borehole depth : 55m

Contact Now

Refurbished Shacman SR150 rotary drilling rig with friction/interlock kelly bar and parts

SR150C is a 150kN rotary drilling rig produced by Beijing Shacman Heavy Machinery Co., Ltd., with a maximum drilling depth of 1.5m, mainly used for industrial and civil construction. The engine is configured with Isuzu CC-6BG1TRP, with load sensing and automatic output power adjustment functions, reducing fuel consumption by 5-10%.

SR150 is the only professional rotary drilling chassis using Kawasaki load control system in China, which is energy-saving and efficient. Fast confluence technology for main winch, with a maximum speed of 82m/min. The effective construction efficiency of the complete machine is 10% higher than that of competitors' equivalent models.

Product Info.:

Basic description
Overall height in working state 18432mm
Maximum borehole diameter 1500mm
Maximum borehole depth 55m
Working weight (including kelly bar) 46t
Bit performance
Maximum output torque of power bit 150kN.m
Bit resolution 6.5-40rpm
Pressure performance
Press of pressure system 150kN
Pull force of pressure system 160kN
Stroke of pressure system 4250mm
Main/auxiliary winch
Lifting force of main winch (first layer) 160kN
Steel wire rope diameter of main winch 28mm
Maximum speed of main winch 70m/min
Lifting force of auxiliary winch (first layer) 60kN
Steel wire rope diameter of auxiliary winch 14mm
Maximum speed of auxiliary winch 60m/min
Forward inclination angle of mast 5°
Left/right inclination angle of mast 5°
Basic Parameters
Engine model CC-6BG1TRP
Engine power kW(HP)125(168)@2100rpm
Displacement 6.494mm
Emission standard EU Stage II
chassis length 6310mm
Unfolding width of chassis 4100mm
Crawler width 700mm
Rotation radius of tail 3980mm

Product Show

Shacman SR150 Refurbished Rotary Drill Rig Second Hand Borewell Machine 18432mmShacman SR150 Refurbished Rotary Drill Rig Second Hand Borewell Machine 18432mmShacman SR150 Refurbished Rotary Drill Rig Second Hand Borewell Machine 18432mmShacman SR150 Refurbished Rotary Drill Rig Second Hand Borewell Machine 18432mmShacman SR150 Refurbished Rotary Drill Rig Second Hand Borewell Machine 18432mm
